Advantech Launches TPC-71W Next-Generation Arm®-Based Industrial Panel PC for IoT Applications

13-06-2019
article-pic
iFactory

Taipei, Taiwan, June 2019 – Advantech, a leading provider of industrial computing platforms, is pleased to announce TPC-71W – the new generation of its industrial panel PCs aimed at machine automation and web-terminal applications. TPC-71W is a cost-efficient, Arm ® -based industrial panel PC that features a 7” true-flat display with P-CAP multi-touch control and an NXP® Arm® Cortex®-A9 i.MX 6 dual/quad-core processor to deliver high-performance computing. The system also features a serial port with a 120Ω termination resistor that supports the CAN 2.0B protocol and offers a programmable bit rate of up to 1 Mb/sec. Equipped with the Google Chromium embedded web browser and support for various operating systems, including Android, Linux Yocto, and Linux Ubuntu with QT GUI toolkits, TPC-71W allows system integrators to easily develop and deploy a wide range of industrial applications. The provision of wireless communication technologies, such as Bluetooth, Wi-Fi, and NFC, via a mini PCIe interface simplifies networking and ensures connectivity for data transfers. TPC-71W also features Power over Ethernet (PoE) functionality for powering devices via Ethernet, thereby eliminating the need to build a power infrastructure. Furthermore, the TPC-71W panel PC supports VESA and panel mounting for flexible and convenient installation. Compared to other similar products, TPC-71W is one of the most competitively priced rugged industrial panel PCs currently available on the market. Overall, this powerful, reliable, and cost-effective computing platform provides the ideal solution for IoT implementation and expansion.


Powerful Rugged Design for Industrial Applications

Aimed at the industrial market, TPC-71W is a rugged yet compact, fanless panel PC equipped with an NXP® Arm® Cortex®-A9 i.MX 6 dual/quad-core processor, 2 GB DDR3L RAM, and 8 GB eMMC storage to provide high-performance computing and improved efficiency for high-tier industrial applications. The 7” true-flat display with 16:9 aspect ratio features P-CAP multi-touch control for easy and intuitive operation. Moreover, to ensure reliable operation in harsh industrial environments, TPC-71W supports a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and is IP66 rated for protection from dust, oil, and water ingress.

Supports Various OS to Enable Rapid Development

TPC-71W supports various OS, including Android 6, Linux Yocto 2.1, and Linux Ubuntu 16.04 with QT GUI toolkits. Linux is an open-source OS specifically designed to assist system integrators with developing unique applications. The ability to support both Android and Linux eliminates software porting efforts and ensures easy deployment. Moreover, TPC-71W features the Google Chromium embedded web browser that simplifies programming and further facilitates application development.

Increased Connectivity for Web-Based Management

To ensure connectivity for web-based management, TPC-71W offers Bluetooth, Wi-Fi, and NFC wireless communication capabilities via a mini PCIe interface. The inclusion of a serial port that supports industrial communication interfaces, such as RS-232/485 and the CAN 2.0B protocol, and a LAN port that supports speeds of up to 1000 Mbps (10/100/1000 Mbps) accelerates data transfer rates, while also enabling Wake-on-LAN functions. Furthermore, the TPC-71W panel PC can be equipped with optional PoE functionality for powering devices via Ethernet; this greatly streamlines installations and reduces overall equipment costs.

Key Features

  • 7” WSVGA LCD with 16:9 aspect ratio and P-CAP multi-touch control
  • NXP® Arm® Cortex®[C1] -A9 i.MX 6 dual/quad-core processor
  • Up to 2 GB DDR3L RAM and 8 GB of eMMC storage onboard
  • 10/100/1000 Mbps LAN Optional PoE functionality for powering devices via Ethernet
  • Supports Linux Yocto, Linux Ubuntu, and Android OS

Advantech’s TPC-71W 7” industrial panel PC is available for order now. For more information about this or other Advantech products and services, contact your local sales support team or visit our website at www.advantech.com
